Description
Technical Features
| Device model | RF-GZF4 | RF-GZF6 |
| Filling nozzle | 4 | |
| Filling range | 100-5000ML | |
| Filling speed (BPH) | 96-1200 | 1400-1800 |
| Filling accuracy | ±1% (Accuracy varies by capacity) | |
| Range of bottle height | 80-180ML (Customizable) | |
| Range of bottle width or diameter | 60-100ML (Customizable) | |
| Power | 1KW 220V | 1.2KW 220V |
| Working air pressure | 0.6-0.8MPA | |
| Machine weight (KG) | 400 | 450 |
| Outline dimension (MM) | 2000*1300*2100 | 2000*1400*2200 |
Frequently Asked Questions
What types of products can this filling machine handle?
The automatic magnetic pump filling machine is designed for vinegar, floral water, eye drops, alcohol, and other thin liquids. The magnetic pump technology provides gentle, accurate filling for sensitive liquid products.
What models are available and what are their specifications?
Two models are available: RF-GZF4 with 4 filling nozzles and RF-GZF6 with 6 filling nozzles. Filling speed ranges from 96-1200 BPH (RF-GZF4) to 1400-1800 BPH (RF-GZF6), depending on fill volume and liquid type.
What is the filling range and accuracy?
The machine offers a filling range of 100-5000ml with ±1% filling accuracy (accuracy varies by capacity). The magnetic pump system ensures precise volumetric dosing for thin liquid products.
What are the bottle size specifications?
The machine accommodates bottle heights of 80-180mm and bottle widths or diameters of 60-100mm, both customizable. The flexible bottle handling system supports various container formats.
What are the power and air pressure requirements?
RF-GZF4 requires 1KW at 220V, while RF-GZF6 requires 1.2KW at 220V. Working air pressure is 0.6-0.8MPa for both models. The low power consumption makes it cost-effective for continuous operation.
What are the machine dimensions and weight?
RF-GZF4 measures 2000mm x 1300mm x 2100mm and weighs 400kg. RF-GZF6 measures 2000mm x 1400mm x 2200mm and weighs 450kg. Both models feature a compact design relative to their production capacity.
How does the magnetic pump technology benefit filling operations?
The magnetic pump drive provides smooth, pulsation-free filling that is gentle on sensitive liquids. It prevents foaming and splashing, making it ideal for products like vinegar, alcohol, and eye drops where product integrity is critical.
