High Speed Automatic Tube Filler Sealer With Steel Stamping
The SunAura high speed automatic tube filler sealer with steel stamping is engineered for precise filling and sealing of plastic, laminated, and aluminum tubes. With a production capacity of 40-60 tubes per minute and a filling range of 5-300ml, it achieves ±0.5~1% filling accuracy. The SIEMENS PLC control system with touch screen interface ensures reliable operation and real-time monitoring for pharmaceutical, cosmetic, and chemical tube packaging applications.
Product Description
The automatic tube filler sealer combines precision filling technology with steel stamping sealing mechanism to produce secure, professional tube packaging. The machine handles tube diameters from φ10mm to φ50mm and tube lengths from 50mm to 200mm, accommodating a wide variety of tube sizes and materials including plastic, laminated, and aluminum tubes.
The steel stamping sealing system creates airtight, tamper-evident seals that meet pharmaceutical and cosmetic industry standards. The SIEMENS PLC with touch screen HMI provides recipe management for different tube formats, production data logging, and remote diagnostic capabilities. The 304 stainless steel construction and 1500kg robust frame ensure long-term reliability in demanding production environments.
Technical Features
| Machine Material | 304 stainless steel |
| Filling Range | 5-300ml (customizable) |
| Suitable Materials | Plastic, Laminated, Aluminum Tubes |
| Production Capacity | 40-60 tubes/minute |
| Filling Accuracy | ±0.5~1% (Depending on product viscosity) |
| Tube Diameter | φ10-φ50mm (customizable) |
| Tube Length | 50-200mm (customizable) |
| Control System | SIEMENS PLC + SIEMENS Touch Screen |
| Voltage (V/Hz) | 220V/380V, 50/60Hz (customizable) |
| Machine Dimensions | 2500L×750W×2400H mm |
| Net Weight | 1500kg |
Key Features
- Steel Stamping Sealing: Precision steel stamping mechanism creates airtight, tamper-evident seals on plastic, laminated, and aluminum tubes, meeting pharmaceutical and cosmetic packaging standards.
- 40-60 Tubes/Min High Speed: High-speed production capacity of 40-60 tubes per minute meets demanding production requirements while maintaining consistent fill accuracy and seal quality.
- ±0.5~1% Filling Accuracy: Precision filling system delivers accurate volume control across the 5-300ml filling range, adapting to different product viscosities from creams to gels.
- Multi-Material Tube Support: Handles plastic, laminated, and aluminum tubes with quick-change tooling, eliminating the need for separate machines for different tube materials.
- SIEMENS PLC Control: Industrial-grade SIEMENS PLC with touch screen HMI provides recipe management, production data logging, real-time monitoring, and remote diagnostic capabilities.
- Wide Tube Size Range: Accommodates tube diameters from φ10mm to φ50mm and tube lengths from 50mm to 200mm, covering most standard tube packaging formats.
- 304 Stainless Steel Construction: Pharmaceutical-grade materials throughout product contact areas, meeting GMP, FDA, and CE compliance standards for hygienic operation.
- Automatic Tube Feeding: Integrated tube feeding system automatically loads and orientates tubes, reducing manual labor and ensuring continuous high-speed production.
- No-Tube No-Fill Safety: Intelligent sensor system prevents filling and sealing operations when no tube is present, reducing product waste and preventing machine damage.
- Robust Industrial Frame: Heavy-duty 1500kg frame construction ensures long-term stability and reliability in demanding high-speed production environments.
Application Industries
- Pharmaceutical Industry: Filling and sealing of ointment tubes, cream tubes, gel tubes, and pharmaceutical packaging with tamper-evident steel stamping seals.
- Cosmetics & Personal Care: Packaging of hand cream, face cream, toothpaste, hair care products, and cosmetic tubes with professional seal quality.
- Food Industry: Filling and sealing of food paste tubes, condiment tubes, and edible product packaging with food-grade compliant materials.
- Chemical & Adhesive Industry: Packaging of adhesive tubes, sealant tubes, lubricant tubes, and chemical product packaging with secure sealing.
- Healthcare & Medical: Filling of medical ointment tubes, antiseptic cream tubes, and healthcare product packaging meeting pharmaceutical standards.
- Veterinary Products: Packaging of veterinary ointment tubes, animal care products, and veterinary pharmaceutical packaging with precise filling.
Frequently Asked Questions
What types of tubes can this machine fill and seal?
The machine handles plastic, laminated, and aluminum tubes with diameters from φ10mm to φ50mm and lengths from 50mm to 200mm. This covers most standard tube formats used in pharmaceutical, cosmetic, and chemical industries.
What is the production capacity of the tube filler sealer?
The machine produces 40-60 tubes per minute, making it suitable for medium to high-volume production. The speed can be adjusted based on tube size, filling volume, and product viscosity.
How does the steel stamping sealing mechanism work?
The steel stamping mechanism applies precise pressure and heat to create airtight, tamper-evident seals on tube ends. This sealing method meets pharmaceutical and cosmetic industry standards for product safety and integrity.
What is the filling accuracy of this machine?
The machine achieves ±0.5~1% filling accuracy depending on product viscosity. The precision filling system handles volumes from 5ml to 300ml, adapting to different product consistencies from thin gels to thick creams.
What control system does the machine use?
The machine is equipped with a SIEMENS PLC and SIEMENS touch screen HMI. This industrial-grade control system provides recipe management for different tube formats, production data logging, real-time monitoring, and remote diagnostic capabilities.
Can the machine be customized for different tube sizes?
Yes, the machine supports tube diameters from φ10mm to φ50mm and tube lengths from 50mm to 200mm. Quick-change tooling enables fast format changeover between different tube sizes. The filling range of 5-300ml is also customizable.
Is the machine suitable for pharmaceutical applications?
Yes, the 304 stainless steel construction and steel stamping sealing meet GMP, FDA, and CE standards for pharmaceutical applications. The tamper-evident sealing and precision filling ensure product safety and regulatory compliance.
Get In Touch
Looking for a high-speed tube filler sealer with steel stamping? SunAura Machinery provides customized tube filling and sealing solutions with CE certification, SIEMENS PLC control, and factory direct pricing.
